Excellent Insulation Thermal Conductive Silicone Insulation Cloth Gray Insulating Silicone Fiberglass Fabric Cloth

Material:
Availability:
Product Description

photobank (15)

Technical Data Sheet

Test Item
Typical vale
Unit
Standard
Color
Gray/Blue/Pink
-
Visual
Thermal Conductivity
1.0-20
W/m.k
ASTM-D5470
Hardness
20±5
Shore A
ASTM-D2240
Thickness
0.3~10
Mm
ASTM-D374
Specific Gravity
2.5~3.5
Mm
ASTM-D2240
Density
2
g/cm³
ASTM-D792
Tensile Strength
2.5
KN/m
ASTM-D412
Breakdown Voltage
>6
KV/mm
ASTM-D149
Flammability Test
V0
V0
UL94
Continuous Use Temperture
-40 ~200
Typical

photobank (8)

22散热硅胶片3导热硅胶片19photobank (3)photobank (10)photobank (11)photobank (12)photobank (13)photobank (14)

photobank (1)photobankphotobank (2)
